SmartSafe TTM313 | Laser Tire Tread Depth Scanner & Examiner

SmartSafe TTM313 Laser Tire Tread Depth Scanner

SmartSafe TTM313 Tire Tread Depth Examiner is the latest handheld laser detector designed specifically for modern automotive repair centers and tire shops. It provides a fast and highly professional solution for measuring tire tread wear with a remarkable accuracy of up to 0.1mm. Thanks to its innovative structural design, you can easily perform a tire tread depth check without being restricted by the vehicle’s chassis height. Using an advanced line laser, it scans the entire tread surface or a single groove, delivering highly accurate readings in just 3 seconds per tire!

Key Features of the TTM313 Tire Tread Examiner

• Lightning-Fast Scanning: Evaluates and reads single tire data in only 3 seconds, saving valuable time for both technicians and customers.

• Ultimate Laser Precision: Offers an exceptional measurement accuracy of 0.1mm with real-time results displayed on a built-in touch screen.

• Dual Measurement Modes: Supports full groove detection (scanning the entire tread surface at once) or single-groove detection for smaller tire treads.

• Ergonomic & Practical Design: A portable layout that allows for tire scanning without the need to lift the vehicle on a hoist.

• Smart Report Sharing: Automatically generates professional inspection reports including maintenance recommendations. Once connected to Wi-Fi, customers can instantly receive their reports by simply scanning a QR code.

• Wide Tire Coverage: Features a 180mm laser measurement width, making it compatible with almost all tire specifications on the market.

What Can This Tire Scanner Solve in Your Shop?

This device is tailor-made for professionals to speed up the workflow and boost tire sales by providing customers with undeniable, data-backed evidence.

1. Tire Tread Depth Measurement: Supports one-time measurement of the entire tread surface or individual grooves to accurately determine the wear percentage.

2. Professional Test Reports: Quickly generates a comprehensive tire tread inspection report displaying tread data, wear analysis, estimated braking distance, and replacement recommendations.

3. Detection Parameter Settings: Supports configuring the number of tires (up to 6 tires for family and commercial vehicles), as well as adjusting tread depth standards and measurement units.

4. Integration with SmartSafe Terminals: The TTM313 works flawlessly as a standalone device, but also supports seamless wireless connection with SmartSafe diagnostic tools (like ST13 / P13 / P03). This allows you to synchronously display and save tire measurement results within the vehicle’s main diagnostic report.

5. Equipment Calibration: Comes with a calibration block, allowing users to independently calibrate the device’s measurement accuracy whenever needed.

6. Smart Android System: Features a touch screen, dual-band Wi-Fi, Bluetooth, language switching, and OTA software updates.

For more information about Tire Tread Examiner Contact CompuCar by WhatsApp From here

Technical Specifications of SmartSafe TTM313

• Measurement Accuracy: 0.1mm.

• Maximum Measured Width: 180mm.

• Processor (CPU): RK3326 Quad-core.

• Memory (RAM): 2GB.

• Storage Capacity: 32GB.

• Display: 3.97-inch LCD touch screen (480×800 resolution).

• Measuring Camera: 2 Megapixels.

• Photography Camera: 8 Megapixels.

• Battery: 5000mAh / 3.7V (Built-in rechargeable battery).

• Charging Input: DC 5V/2A.

• Communication Modes: Wi-Fi (Supports 2.4GHz/5GHz dual-band) & Bluetooth.

• Operating Temperature: 0°C to 45°C.

CompuCar Guarantee: Your Investment in Safe Hands

• Authorized Dealer: We are the authorized dealer for SmartSafe and Launch in Saudi Arabia, ensuring you receive 100% genuine and original equipment.

• 2-Year Comprehensive Warranty: The device comes with a real 24-month warranty to protect your investment.

• Ongoing Technical Support: We provide a professional technical support team ready to assist you in generating reports and linking the device with other diagnostic equipment in your workshop.
